A spectrum analyzer is an essential tool for measuring and visualizing the frequency components of radio signals. It helps engineers identify interference, measure signal power, verify transmission quality, and ensure system performance across various wireless communication networks. In modern communication environments — especially with the rise of 5G and dense RF deployments — accurate spectrum analysis is vital for maintaining signal integrity and reducing troubleshooting time.
Product features
| Frequency range | 9 kHz ~ 1.6 GHz |
| Displayed Average Noise Level (DANL) | -135 dBm (typical value, preamplifier on) |
| Phase noise | -80 dBc/Hz @10kHz offset |
| Resolution Bandwidth (RBW) | 10 Hz ~ 1 MHz (1-3-10 sequence) |
| Video Bandwidth (VBW) | 1 Hz ~ 1 MHz |
| Amplitude accuracy | <1.5 dB |
| Input attenuation range | 0 ~ 51 dB (1dB step) |
| Reference level range | -100 dBm ~ +30 dBm |
| Screen | 5.7-inch LCD, 600×480 |
| Communication interface | LAN, USB Host/Device, SD card slot |
| power supply | DC 12-17V / AC adapter |
| Operating Temperature | -10℃ ~ +50℃ |
Educational experiments: Communication principles, RF circuit teaching
R&D debugging: wireless module and RF device performance verification
Production testing: testing of passive/active components such as filters and amplifiers
On-site maintenance: signal coverage detection, interference troubleshooting
A spectrum analyzer is an essential tool for measuring and visualizing the frequency components of radio signals. It helps engineers identify interference, measure signal power, verify transmission quality, and ensure system performance across various wireless communication networks. In modern communication environments — especially with the rise of 5G and dense RF deployments — accurate spectrum analysis is vital for maintaining signal integrity and reducing troubleshooting time.
A spectrum analyzer is an essential tool for measuring and visualizing the frequency components of radio signals. It helps engineers identify interference, measure signal power, verify transmission quality, and ensure system performance across various wireless communication networks. In modern communication environments — especially with the rise of 5G and dense RF deployments — accurate spectrum analysis is vital for maintaining signal integrity and reducing troubleshooting time.
A powerful and comprehensive device to measure and display the frequency components and signal strength of RF signals. A spectrum analyzer is an essential tool for measuring and visualizing the frequency components of radio signals. It helps engineers identify interference, measure signal power, verify transmission quality, and ensure system performance across various wireless communication networks. In modern communication environments — especially with the rise of 5G and dense RF deployments — accurate spectrum analysis is vital for maintaining signal integrity and reducing troubleshooting time.
